INQUIRYProduct Feature
- It is not squeeze type. Do not waste ink. Use screen print type.
- Selectiveness of plug hole, does not change original production process.
- Foundation by blind-bore type with high aspect ratio board. If printing two times the hole no air- bubble.
- Printing and frame seat use servo motor control that is more easy operator and set.
- No troubles about groove and pipeline cleaning.
Product Specification
| Item | Specification |
|---|---|
| Power | AC220V,380V,3PH,12KW |
| Supply Height | 1000±50mm |
| Compression | 6-8 kg/cm2, 30 l/min |
| Printing table | 700x900 mm |
| Printing Area | MAX: 600x600mm MIN:250 x250mm |
| Frame size | MAX: L1100xW1050mm MIN: L1000xW800mm |
| Machine Weight | 6800kg |
| Dimension | L2500xW1500xH2200mm |
